Service Tiers – Relational Databases in Azure

Service Tiers

Azure SQL Database service tiers are different for each purchasing model. The DTU-based purchasing model offers Basic, Standard, and Premium tiers. Table 2.4 lists some of the common characteristics of these tiers.

TABLE 2.4  DTU-based purchasing model service tier characteristics

CharacteristicBasicStandardPremium
DTUs5S0: 10
 S1: 20
 S2: 50
 S3: 100
 S4: 200
 S6: 400
 S7: 800
 S9: 1600
 S12: 3000
P1: 125
 P2: 250
 P4: 500
 P6: 1000
 P11: 1750
 P15: 4000
Included Storage2 GB250 GBP1–P6: 500 GB
 P11 and above: 4 TB
Maximum Storage2 GBS0–S2: 250 GB
 S3 and above: 1 TB
P1–P6: 1 TB
 P11 and above: 4 TB
Maximum backup retention7 days35 days35 days
CPULowLow, Medium, HighMedium, High
IOPS1–4 IOPS per DTU1–4 IOPS per DTU>25 IOPS per DTU
IO Latency5 ms (read), 10 ms (write)5 ms (read), 10 ms (write)2 ms (read/write)
Columnstore IndexesN/AS3 and aboveSupported
In-Memory OLTPN/AN/ASupported

The vCore-based purchasing model offers the following three service tiers:

  • General Purpose is used for most business workloads. This tier offers balanced compute and storage options.
  • Business Critical is used for business applications that require high I/O performance. It is also the best option for applications that require high resiliency to outages by leveraging a SQL Server Always On availability group for HA.
  • Hyperscale is used for very large OLTP databases (>4 TB) and can automatically scale storage and compute. Hyperscale databases use local SSDs for local buffer-pool cache and data storage. Long-term data storage is done with remote storage.

Table 2.5 lists the common characteristics for the vCore-based purchasing model service tiers:

TABLE 2.5  vCore-based purchasing model service tier characteristics

CharacteristicGeneral PurposeBusiness CriticalHyperscale
StorageUses remote storage.
 Provisioned Compute: 5 GB–4 TB
 Serverless Compute: 5 GB–4 TB
Uses local SSD storage
 Provisioned Compute: 5 GB–4 TB
Supports up to 100 TB
Availability1 replica, no read-scale replicas3 replicas, 1 read-scale replica1 read-write replica, 0–4 read-scale replicas
In-MemoryNot SupportedSupportedPartial Support
